AV-1232
-
AV-1232Model Element no. Channel Frequency Range Antenna Gain Beam Width H/V Front-back Ratio Impedance Antenna Length AV1232 19 21-60 470-790Mhz 10-15dB H32°/V35° 15-28dB 75 Ω 1042mm
-
| Model | Element no. | Channel | Frequency Range | Antenna Gain | Beam Width H/V | Front-back Ratio | Impedance | Antenna Length |
| AV1232 | 19 | 21-60 | 470-790Mhz | 10-15dB | H32°/V35° | 15-28dB | 75 Ω |
1042mm |
